Image Sensor

Original CMOS

Original CMOS

Original CMOS

1/2 inch CCD

Shutter Mode

Global

Rolling

Global

Global

Active Image
Area (HxV)

7.2x7.68mm

10x10mm

5.76x4.8mm

6.4x4.8mm

Active Pixels
(HxV)

240x256
(fixed)

100x100
(fixed)

92x24

40x28

92x40

88x60

92x80

184x124

188x160

376x252

Pixel Size

30μmx30μm

100μmx100μm

30μmx30μm

8.4μmx9.8μm

Maximum Teporal Resolution

1.0ms

0.1ms (1 cam)
0.2ms(2 cam)

0.2ms@92x24

1.3ms@40x28

0.3ms@92x40

2.2ms@88x60

0.6ms@92x80

3.7ms@184x124

1.2ms@188x160

7.0ms@376x252

Well-Depth

500,000e-

1,500,000e-

450,000e-

100,000e-

Number of Slot

For camera interface board: 2, For optional unit: 1

A/D converter

14 bit

Maximum Recordable Frame Number

Dependent on camera used and image acquisition settings

Recording Mode

Temporary storage to PC RAM before saving
or
Direct data saving to PC drive

Buffer Memory
inside
DataProcessor

1GB or 4GB (optional)

Data Transfer
Mode

USB3.0 (for basic functions), USB2.0 (for optional functions)

Inputs

Analog Signal (4ch), External Trigger Signal, Frame Sync Signal

Outputs

Trigger Wait Signal (TTL), Stimulation Pulse (TTL, 2ch),
Lighting Control Signal for Light Source (TTL),
Light Intensity Control Signal for Light Source (Voltage/Amplitude),
Frame Sync Signal, Real Time Light Intensity Monitor Signal (8 pixels)

Trigger Mode

Software, TTL External Input,
Analog External Input, Usage of Optional Unit

Stimulus Output
Start Timing

Image Acquisition Start, Lighting Control Signal Output,
Trigger Signal Input/Output

Camera Mount

C mount

Standard System Configuration

Camera Head (1-4), Processor, PC, monitor, data acquisition software

Options
(sold separately)

Image Analysis Software (BV_Ana)
Real Time Light Intentisy Monitor Function (ROM and sotware)

Supported OS

Windows 7/8.1 64 bit

Power Supply

AC 85V-240V
